Product Description
The advanced Multi-CAM 3500FX autofocus sensor offers 51 AF points with 15 cross-type sensors and Group Area AF enables five AF sensors to be used as one group. This is useful when shooting subjects that cannot be tracked easily by one AF point due to lighting conditions.
As a camera optimized for video capture, the D810 features recording in both FX and DX formats including simultaneous recording to memory cards and an external recorder as well as recording 60p output to an external recorder. The ISO range for video has also been expanded to run from ISO 64 to 12,800 and expand to 51,200. Automatic ISO adjustment in manual mode enables smooth exposure transitions. A built-in stereo microphone is supported as are jacks for an external mic and headphones. A selectable audio frequency range provides exacting control over sound recording.
A 3.2" LCD with 1,229K-dot resolution provides playback viewing and live view, and improved coatings on the optical viewfinder components provide brighter images and more accurate colors. Live View function now includes split screen display zoom for stills, and zebra highlighting display in video mode. Full aperture metering during live view for still shooting is supported.
Interval and time-lapse shooting feature exposure smoothing, and the maximum number of images per sequence is now 9,999. Improved Picture Control settings now offer Flat Picture Control to enable maximum dynamic range and color adjustments in post-production.
The D810 utilizes dual media slots for both Compact Flash and SD cards, and it provides a built-in flash with i-TTL metering as well as a hot shoe mount. A larger grip enables comfortable control for extended shooting, and a secondary "i" button has been added to back panel for faster access to important settings.
| Imaging | |
| Lens Mount | Nikon F |
| Camera Format | Full-Frame (1.0x Crop Factor) |
| Pixels | Actual: 37.09 Megapixel Effective: 36.3 Megapixel |
| Max Resolution | 7360 x 4912 |
| Aspect Ratio | 3:2 |
| Sensor Type / Size | CMOS, 35.9 x 24.0 mm |
| File Formats | Still Images: JPEG, RAW, TIFF Movies: MOV, MPEG-4 AVC/H.264 Audio: Linear PCM |
| Bit Depth | 14-Bit |
| Dust Reduction System | Yes |
| Memory Card Type | CompactFlash SD SDHC SDXC |
| Focus Control | |
| Focus Type | Autofocus |
| Focus Mode | Continuous-Servo AF (C), Manual Focus (M), Single-servo AF (S) |
| Autofocus Points | 51 (15 Cross-Type) |
| Viewfinder/Display | |
| Viewfinder Type | Pentaprism |
| Viewfinder Eye Point | 17.00 mm |
| Viewfinder Coverage | 100% |
| Viewfinder Magnification | Approx. 0.70x |
| Diopter Adjustment | -3 to +1 m |
| Display Screen | 3.2" Rear Screen LCD (1,229,000) |
| Screen Coverage | 100% |
| Diagonal Angle of View | 170.0° |
| Exposure Control | |
| ISO Sensitivity | Auto, 64-12800 (High Sensitivity Mode: 32-51200) |
| Shutter | Type: Electronic & Mechanical Speed: 30 - 1/8000 Seconds , Bulb Mode |
| Mirror Lock-Up | Yes |
| Metering Method | 3D Color Matrix Metering, Center-Weighted Average Metering, Spot Metering, Highlight Weighted |
| Exposure Modes | Modes: Aperture Priority, Manual, Programmed Auto, Shutter Priority Metering Range: EV 0.0 - EV 20.0 Compensation: -5 EV to +5 EV (in 1/3, 1/2 or 1 EV Steps) |
| White Balance Modes | Auto, Cloudy, Color Temperature, Direct Sunlight, Flash, Fluorescent, Fluorescent (Cool White), Fluorescent (Day White), Fluorescent (Daylight), Fluorescent (Natural White), Fluorescent (Warm White), Fluorescent (White), Incandescent, Preset Manual, Shade |
| Flash | |
| Flash Modes | Auto First-Curtain Sync Off Rear Curtain/Slow Sync Rear Sync Red-Eye Reduction Slow Sync Slow Sync/Red-Eye Reduction |
| Built-in Flash | Yes |
| Maximum Effective Flash Range | Up To 39' (11.89 m) |
| Guide No. | 39' (11.89 m) ISO100 |
| Max Sync Speed | 1 / 250 Second |
| Flash Compensation | -3 EV to +1 EV (in 1/3, 1/2 or 1 EV steps) |
| Dedicated Flash System | iTTL |
| External Flash Connection | Hot Shoe, PC Terminal, Wireless |
| AV Recording | |
| Video Recording | Yes, NTSC |
| File Size | 1920 x 1080p (Full HD) 1280 x 720p (HD) |
| Frame Rate | @ 1920 x 1080: 60 fps, 30 fps, 24 fps, 50 fps, 25 fps @ 1280 x 720: 60 fps, 50 fps |
| Exposure Control | Auto: Shutter Speed, Aperture, ISO Manual: Shutter Speed, Aperture, ISO |
| ISO Sensitivity | 64 - 12800, Expandable to 51200 |
| Focus | Auto Manual Continuous Auto |
| Max Video Clip Length | 1920 x 1080 at 60 fps: 20 Minutes 1920 x 1080 at 50 fps: 20 Minutes 1920 x 1080 at 30 fps: 29 Minutes, 59 Seconds 1920 x 1080 at 25 fps: 29 Minutes, 59 Seconds 1920 x 1080 at 24 fps: 29 Minutes, 59 Seconds 1280 x 720 at 60 fps: 29 Minutes, 59 Seconds 1280 x 720 at 50 fps: 29 Minutes, 59 Seconds |
| Audio Recording | Built-In Mic: With Video (Stereo) Optional External Mic: With Video (Stereo) |
| Performance | |
| Start-up Time | 0.12 seconds |
| Shutter Lag | 0.052 seconds |
| Self Timer | 2 Seconds, 5 Seconds, 10 Seconds, 20 Seconds Custom: 1 - 20 Seconds at 0.5-, 1.0-, 2.0-, 3.0Second Intervals Number of Shots: 1 - 9 |
| Interval Recording | Yes |
| Connectivity | 1/8" Headphone, 1/8" Microphone, HDMI C (Mini), USB 3.0 Micro-B |
| Wi-Fi Capable | Yes (with Optional Transmitter) |
| Power | |
| Battery | 1 x EN-EL15 Rechargeable Lithium-Ion Battery Pack, 7.0 VDC, 1900 mAh |
| AC Power Adapter | EH-5b (Optional) |
| Operating/Storage Temperature | Operating 32 to 104°F (0 to 40°C) Humidity: 0 - 85% |
| Physical | |
| Dimensions (W x H x D) | 5.7 x 4.8 x 3.2" / 146.0 x 123.0 x 81.5 mm |
| Weight | 31.04 oz / 880 g |
| Warranty Length |
